Introduction
P3.9 Glass Window Transparent LED Display Screen, because of its special mechanism design, can help solve many scenarios where conventional screens cannot be applied. First of all, this transparent display uses lighter engineering aluminum profiles, so that its weight per square meter is only a few kilograms, which makes its transportation and disassembly more convenient, and a single person can also achieve installation and safety. Sex is also more secure. At the same time, it provides better transparency. The traditional LED window display is like a dark wall, users can't see what products are inside, and it blocks the sunlight from entering, but our transparent display allows users to see the products inside clearly through the window. In addition, this unique display form is also an effective means to attract audiences.
Features
Small, medium, large, and even ultra-large LED displays can theoretically be manufactured. Our P3.9 Glass Window Transparent LED Display Screen is available in various sizes and each product can achieve high-quality display brightness, display resolution, and transparency. At the same time, the lightweight modular framework is optimized to ensure perfect alignment when assembled into the finished product. In addition, it can quickly implement regular graphics or video playback updates. For some special display content, you can also use a computer to program. The intuitive operation interface makes updating the content only need a few steps to complete.
Item | P3.91 Semi-Outdoor Glass Window Transparent Led Display Board |
Model Number | p3.91 |
Pixel Pitch | 3.91mm |
Pixel Density(dots/m²) | 32768 |
Pixel Configuration | 3 IN 1 |
LED Type | SMD2020 |
Module size(mm) | 250*250 |
Module Resolution(dots) | 64*64 |
Min.Viewing Distance(m) | ≥3.91 |
Brightness(cd/m²) | >5000 |
Viewing Angle(degree) | ≤140° |
Average Power Consumption(w/m²) | 550~850W |
Scan Mode | 1/8S |
Protection Level | IP65 |
Cabinet Size(mm) | 500*1000 |
Color Temperature | The brightness of R.G.B.is adjustable according to software 100level;Color temperature is adjustable in terms of detailed requirements |
Input Voltage | AC220 V/50HZ or AC 110V/60HZ |
Refresh Rate | LED screen refresh frame frequency recommended is no less than 1200HZ(recommended) |
Color | 64g color(on the condition of 4096 gray scale) |
Horizontal/Vertical viewing angle | <140° |
Gray Scale | Recommended 14BIT |
Effective Communication Distance(without relay) | Unshielded twisted-pair net line transmission distance is 100 meters,max transmission distance is 130 meters. |
FAQ
Q1:Are you a manufacturer or trading company?
A1:We are a Professional OEM/ODM manufacturer which has specialized in led display industry for more than 17 years.
Q2:How does your factory do regarding quality control?
A2:Quality is priority.Brighter people always attach great importance to quality controlling from the very beginning to the very end. We focus on every detail,Our factory has gained ISO9001, ISO14001, CE, RoHS ,FCC authentication.
Q3:What is your MOQ?
A3:Any quantity is acceptable for your order. And the price is negotiable for large quantity.
Q4:When will you make the delivery?
A4:We can make the delivery within 3-5 working days for the led modules and 10-12days for the led finished screen according to the size and quantities of your order.
Q5:What technical supports can you offer?
A5:We provide all kinds of technology trainings for free, including the operation and maintenance training of the LED screens in our factory. we can send an engineer team to the country of the customer to instruct the installation.
Q6:How long is the warranty?
A6:The standard warranty is 1 year. It could be longer upon request.
Q7:Do you provide any free spare parts in each order?
A7:Yes, a certain amount of spare parts will be provided for free, spare parts including module, power cable,signal cable, LED lamp, IC, mask, power supply, receiving card, etc.
Good service After-sale
1.Two years warranty for the whole system except human factor and force majeure
2.Three years quality warranty, lifetime maintenance, and guarantee the maintenance time in contract.
3.During the warranty period: solve problems for users through the phone, fax or E-Mail. Update the software free of charge.
4.As to the product quality problems caused by design, manufacture, installation technology, material, the replacement and maintenance are free. The system damage caused by force majeure(flood, fire, earthquake, war and so on) as well as users) man-made disturbance(construction, cleaning ) should be coordinate by both sides to solve.
